Motherboard GIGABYTE X870E AORUS MASTER X3D, Chipset AMD X870E, Socket AM5, ATX
Soporta Procesadores de escritorio AMD Socket AM5 Ryzen 9000, 8000 y 7000 Series, 4 x ranuras de memoria DDR5 / maximo de 256GB, Almacenamiento 5 x M.2 Key-M slots / 2 x SATA 6Gb/s, Sonido Realtek ALC1220 + DAC ESS ES9118 con DTS:X Ultra, LAN 1 x Realtek 5GbE + 1 x Realtek 10GbE (RJ-45), WLAN Wi-Fi 7 / Bluetooth v5.4, Formato ATX.
| MARCA | GIGABYTE |
| MODELO | X870E AORUS MASTER X3D |
| CHIPSET | AMD X870E |
| TIPO DE SOCKET | AM5 AMD |
| AMD COMPATIBLE | Procesador AMD Ryzen 9 SAM5 9XXXProcesador AMD Ryzen 7 SAM5 9XXXProcesador AMD Ryzen 5 SAM5 9XXXProcesador AMD Ryzen 3 SAM5 9XXXProcesador AMD Ryzen 3 SAM5 8XXXProcesador AMD Ryzen 9 SAM5 8XXXProcesador AMD Ryzen 7 SAM5 8XXXProcesador AMD Ryzen 5 SAM5 8XXXProcesador AMD Ryzen 9 SAM5 7XXXProcesador AMD Ryzen 7 SAM5 7XXXProcesador AMD Ryzen 5 SAM5 7XXX |
| COMPATIBLES | Memoria RAM DDR5 8200 MHz PC5-65600Memoria RAM DDR5 7600 MHz PC5-60800Memoria RAM DDR5 7200 MHz PC5-57600Memoria RAM DDR5 6800 MHz PC5-54400Memoria RAM DDR5 6400 MHz PC5-51200Memoria RAM DDR5 6000 MHz PC5-48000Memoria RAM DDR5 5600 MHz PC5-44800Memoria RAM DDR5 5200 MHz PC5-41600Memoria RAM DDR5 4800 MHz PC5-38400 |
| NUMERO DE SOCKETS DIMM | 4 |
| EXPANSION MAXIMA EN GB | 256 |
| TECNOLOGIA | AMD EXPODual Channel |
| TIPO DE RAM | DDR5 |
| CHIPSET | Realtek ALC1220 Codec |
| CANALES | 2/4/5.1-channel |
| ETHERNET | CHIPSET Realtek 10 GbERealtek 5GbE |
| VELOCIDAD | 5000 Mbps10000 Mbps |
| CHIPSET 2DO ETHERNET | Realtek 5GbE |
| VELOCIDAD 2DO ETHERNET | 5000 Mbps |
| CHIPSET | MediaTek Wi-Fi 7 |
| PROTOCOLOS | 802.11be |
| BANDAS DE FRECUENCIA | 6 GHz5 GHz2.4 GHz |
| BLUETOOTH VERSION | 5.4 |
| NUMERO DE PUERTOS | 2 |
| VELOCIDAD DE TRANSFERENCIA | 6 Gbit/s |
| RAID SATA | RAID 1RAID 0 |
| NUMERO TOTAL DE SLOTS M.2 KEY M | 5 |
| 1 x PCIe 5.0 x4 tipos | 22802580 |
| 1 x PCIe 5.0 x4 tipos | 2280 |
| 2 x PCIe 4.0 x4 tipos | 2280 |
| 1 x PCIe 4.0 x2 tipos | 2280 |
| RAID PCIe o NVMe | RAID 10RAID 5RAID 1RAID 0 |
| PCI Express CPU | PCI Express x16 slot, PCIe 5.0 modo x16 1 |
| PCI Express x16 slot, PCIe 5.0 modo x8 | 1 |
| PCI Express x16 slot, PCIe 4.0 modo x4 | 1 |
| USB 3.2 GEN 2X2 TIPO-C | 1 |
| USB 3.2 GEN 2 TIPO-C | 1 |
| USB 3.2 GEN 2 TIPO-A | 7 |
| HDMI | 1 |
| RJ-45 | 2 |
| AUDIO JACKS | 2 |
| OPTICAL S/PDIF OUT | 1 |
| WI-FI / BLUETOOTH ANTENNA | 2 |
| BOTON CLEAR CMOS | 1 |
| USB 4.0 TIPO-C | 2 |
| Q-FLASH PLUS | 1 |
| BIOS | AMI BIOS UEFI |
| FACTOR DE FORMA | ATX |
| DIMENSIONES | 30.5 x 24.4 cm |
| PRESENTACION | CAJA |
| 1 x 24-pin ATX Main Power | 1 |
| 1 x 8-pin ATX 12V power | 2 |
